Cell holder
Notes for users
SPECORD S600 accessories Edition 09/2014 9
1.6 Alignment of accessories
Some of the accessories, e.g. the microcell holder, must be positioned very
accurately in the beam. For this purpose, start an energy measurement using
the measurement parameters listed below. Align the accessory unit the
measured energy has reached its maximum.
Open the measuring parameter window via the menu command Measurement/
Set Parameters.
Option/Input
Adjustment
General card
Display
Energy
Mode card
Fixed wavelengths
Activated
Wavelength
Approx. 500 nm
Transfer the selected wavelength to the field
Choice by clicking +.
Device card
Integration time
In the monitoring mode, adjust the integration
time: menu command Monitor / Autom.
Accumulation
5
Dark current correction
Activated
Interval card
Manual
Activated
Start request
Activated
Accessories card
Accessories
None
Note
First select the mode before optimizing the integration time. The optimal
integration times is different depending on whether you measure at fixed
wavelengths or as you scan a complete spectrum.
