Peltier-tempered accessories
Peltier tempered 6- and 8-cell changers
SPECORD S600 accessories Edition 09/2014 51
15.4 Peltier tempered 6- and 8-cell changers
The Peltier-tempered cell changers are automatic sample changing systems.
The temperature control of the cell changers is carried out via a separate
control unit. The rear of the Peltier elements is kept at a temperature near the
ambient temperature by the water cycle of the heat exchanger.
As control sensor a sensor in the top area of the cell block is used. In addition to
the control sensor the cell changer features two further sensors for the optional
registration of the holder or cell temperature.
The cell sensor is designed specifically for standard cells with round plugs from
PTFE and can remain in the cell during the optical measurement.
The cell changers have space for 6 or 8 cells with a path length of 10 mm and
external dimensions of 12,, (L x W x H in mm).5 x 125 x 45
Optionally the cell changers can be equipped with a magnetic stirrer at factory.
The stirring speed is set at the temperature control unit.
Note!
The 6- and 8-cell changers differ by the cell block used and thus the possible
number of cells to be inserted. However, their operation and installation are
identical. Therefore, the two cell changers are described jointly below. For the
illustrations the 8-cell changer has been used. The 6-cell changer is installed
analog in the sample chamber.
Safety instructions for the use of the Peltier-tempered cell changer
The Peltier-tempered cell changers have been constructed and tested in
accordance with the following standards and guidelines:
• DIN EN 61010-1 (IEC 1010-1)
• DIN EN 55011 class B
• DIN EN 61326-1
• DIN EN 61000-3-2
• DIN EN 61000-3-3
The cell changers left Analytik Jena AG in a sound condition. To maintain this
condition and ensure safe operation observe the safety instructions and the
notices marked with symbols:
Caution! Safety instructions!
When working with the Peltier-tempered cell changers observe the safety
instructions in Chapter "General safety instructions for Peltier-tempered
accessories" p. 37.
