Cell changer
8-cell changer
28 Edition 09/2014 SPECORD S600 accessories
12 8-cell changer
The 8-cell changer is an automatic sample changing system for eight standard
cells.
Design versions
The following additional options are available for the 8-cell changer:
• Magnetic stirrer
• Temperature control using external thermostats
The design of the cell changers is fully configured at factory and an only be
retrofitted by customer service.
Technical data
Cells Path length: 10 mm
Cell width: 12.5 mm
Minimum filling height 25 mm
Radiation height 5 – 15 mm
Temperature
control
By way of external thermostats
Magnetic stirrer Power supply 230 V
Layout
1 Connection for magnetic stirrer (optional)
2 Interface cable to connect to SPECORD
S600
3 Cell block with insulation sleeve
4 Step motor
5 Hoses for thermostat connection
(optional)
6 Base plate with guide rails
7 Stop bolt
8 Control unit for magnetic stirrer (optional)
Fig. 12-1 Layout of the 8-cell changer
