Cell holder
Notes for users
SPECORD S600 accessories Edition 09/2014 7
3 Polychromator
2 Sample compartment with carrying rails for
the installation of accessories
Fig. 1-1 Design of the SPECORD S600
The standard equipment of the device includes the universal holder. It serves as
support for the use of various cell holders and the holder for solid samples.
1 Adapter for cell holders
2 Base plate with feet and pressure
piece
Fig. 1-2 Universal holder
Installing the universal holder
1 Pressure piece (obstructed)
2 Adapter for cell holders
3 Feet
Fig. 1-3 Universal holder installed in SPECORD S600
