SPECORD S600 accessories Edition 09/2014 33
14 Measurement with the cell changer
14.1 Configuring parameters for the cell changer
To perform measurements with a cell changer switch on the SPECORD S600
and start WinASPECT. Open the measuring parameter window via the menu
command Measurement / Set Parameters. Go to the tab Accessories and
select the respective cell changer from the list box.
The dialog boxes for the cell changers are largely identical. They only differ in
the number of samples.
Define the following parameters for the control of the cell changers:
• Sample assignment of the cell changer
• Option of the measuring start
• The cell change during kinetic (cyclical) measurements
Fig. 14-1 Measuring parameter tab Accessories with configurations for 6-cell
changers
Parameter Description
1st position
Using the slider set the position of the first sample in the
cell changer.
Last position
Using the slider set the position of the last sample in the
cell changer.
1st position –
reference
The sample at the “1st position" selected above is treated
as a reference sample.
The reference measurement is automatic after the start of
the measurement at this sample.
