Analytik Jena SPECORD S600 User Manual

Peltier-tempered accessories
Temperature control unit for Peltier-tempered accessories
60 Edition 09/2014 SPECORD S600 accessories
Every opt.
measurement
If activated, an optical measurement is carried out at
each temperature stage.
Cuvette
measurement
sensor active
If enabled the temperature control is via the cell sensor
directly in the sample, otherwise via the sensor in the
cell block.
from no. to no.
diff. °C
Modify the temperature by the same temperature
difference across a specific range.
From No. Number of the first temperature stage
To No. Number of the last temperature stage
Temp. difference °C
Temperature difference between the
individual temperature stages
Transfer the inputs to the table.
[Insert]
Inserts an additional cell (additional temperature range)
at the selected location of the table.
[Delete]
Deletes a selected table cell.
15.5 Temperature control unit for Peltier-tempered
accessories
The control unit implements the temperature control for the Peltier-tempered
accessories.
Technical data
Control unit mass 2.5 kg
Dimensions (W x H x D)
225 x 130 x 200 mm
3
Mains voltage 100 – 240 V
Frequency 50 ... 60 Hz
Power consumption 75 VA
Mains fuses 2 x T 2.5 AH / 250V, type 19181 by
Wickmann
EMC (interference emission and
interference resistance) according to
DIN EN 61326 and 61326/A1
The device may be positioned and
operated anywhere.
Fire resistance of the control unit
housing according to UL94
HB / 1.6
Protection type IP 20
Data connection RS232 interface
Operating temperature range +15°C...+35°C
Transport and storage temperature
range
-40°C...+60°C
relative humidity up to 90% (at +30°C)
