Peltier-tempered accessories
Peltier-tempered cell holder with external heat exchanger
SPECORD S600 accessories Edition 09/2014 47
Safety instructions for the use of the Peltier-tempered cell holder with
heat exchanger
The Peltier-tempered cell holder has been constructed and tested in
accordance with the following standards and guidelines:
• DIN EN 61010-1 (IEC 1010-1)
• DIN EN 55011 class B
• DIN EN 61326-1
• DIN EN 61000-3-2
• DIN EN 61000-3-3
It left Analytik Jena AG in a sound condition. To maintain this condition and
ensure safe operation observe the safety instructions and the notices marked
with symbols:
Caution! Safety instructions!
When working with the Peltier-tempered cell holder observe the safety
instructions in Chapter "General safety instructions for Peltier-tempered
accessories" p.37.
15.3.1 Technical data and layout
Technical data
Principle Thermoelectric heating and cooling
TEC rear cooling water-cooled by connection to a heat
exchanger
Guaranteed controlled
temperature range at 25 °C
ambient temperature *
PTC 101 with heat exchanger:
-5°C...+ 105°C
Preset range of block
temperature
PTC 101 with heat exchanger:
-20°C...+105°C
Preset accuracy 0.1 °C
Display accuracy 0.1 °C
Control accuracy +/- 0.1 °C
