Analytik Jena SPECORD S600 User Manual

Peltier-tempered accessories
Peltier temperature-controlled cell holder, air-cooled
38 Edition 09/2014 SPECORD S600 accessories
15.2 Peltier temperature-controlled cell holder, air-cooled
The Peltier-tempered cell holder allows the temperature control of cells with the
dimensions 12,5 x 12,5 x 45 - 46 (L x W x H in mm) and 10 mm path length.
The temperature control of the cell holder is carried out via a separate control
unit. The rear of the Peltier element is air-cooled via a heat exchanger with
cooling ribs.
As control sensor a Pt100 sensor is used and positioned at the bottom outer
corner of the cell block. The cell holder further features two additional sensors
for the optional registration of the holder or cell temperature.
The cell sensor is designed specifically for standard cells with round plugs from
PTFE and can remain in the cell during the optical measurement.
The cell holder is equipped with a magnetic stirrer by default to achieve a fast
and even temperature distribution in the cell. The stirring speed is set at the
temperature control unit.
Safety instructions for the use of the Peltier-tempered cell holder
The Peltier-tempered cell holder has been constructed and tested in
accordance with the following standards and guidelines:
• DIN EN 61010-1 (IEC 1010-1)
• DIN EN 55011 class B
• DIN EN 61326-1
• DIN EN 61000-3-2
• DIN EN 61000-3-3
It left Analytik Jena AG in a sound condition. To maintain this condition and
ensure safe operation observe the safety instructions and the notices marked
with symbols:
Caution! Safety instructions!
When working with the Peltier-tempered cell holder observe the safety
instructions in Chapter "General safety instructions for Peltier-tempered
accessories" p.37.
15.2.1 Technical data and layout
Principle Thermoelectric heating and cooling
TEC rear cooling air-cooled
Guaranteed controlled temperature
range at 25 °C ambient
temperature
PTC 100 with heat exchanger Typ A
+10...+60 °C
PTC 100 with heat exchanger Typ B
-5...+105 °C
Preset range of block temperature -20 +105 °C
Preset accuracy 0.1 °C
Display accuracy 0.1 °C
Control accuracy +/- 0.1 °C
