W-CDMA/HSPA+ Signal Analyzer 3-12 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 3-33
ACLR Menu
Key Sequence: Measurements > RF Measurements > ACLR
Display Trace: Select On to display the trace.
Select # of Main Channels: Set the main channels from 1 channel to 4
channels.
Select # of Adjacent Channels: Set the adjacent channels from 1 channel
to 4 channels.
Channel Width: Set the bandwidth for the channels for the number of
adjacent channels selected.
Back: Returns to the “RF Measurement Menu” on page 3-31.
Figure 3-24. W-CDMA/HSPA+ ACLR Menu
Back
ACLR
Display Trace
On Off
Select
# of
Main Channels
Select
# of
Adjacent Channels
Channel Width
5.000 MHz
