A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-39
Test Records for Options Verification (continued)
T1 Analyzer Verification, Option 51
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-53. Option 51, T1 Frequency Clock
Measurement Measured Value Specification
Internal Clock Error ± 5 ppm
Recovered Clock Frequency 1543992 to 1544008 Hz
Table A-54. T1 Transmitted Level Voltage
Measurement Measured Value Specification
Tx LBO: 0 dB 4.8 to 7.6 Vp-p
Tx LBO: –7.5 dB 1.9 to 31 Vp-p
Tx LBO: –15 dB 0.5 to 1.7 Vp-p
Table A-55. T1 Transmitted Level Vpp Reading
Measurement Vpp Reading Specification
Tx LBO: 0 dB 4.8 to 7.6 Vp-p
Tx LBO: –7.5 dB 1.9 to 3.1 Vp-p
Tx LBO: –15 dB 0.5 to 1.7 Vp-p
