Anritsu MT8212E - DVB-T;H Signal Analyzer Verification, Options 64 and 57

A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-45
Test Records for Options Verification (continued)
DVB-T/H Signal Analyzer Verification, Options 64 and 57
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-68. Option 64, DVB-T/H Signal Analyzer, Frequency Accuracy for –20 dBm Reference Level
Channel Reference Level Frequency Error Specification
21 –20 dBm Hz ± 0.3 Hz
45 –20 dBm Hz ± 0.3 Hz
69 –20 dBm Hz ± 0.3 Hz
Table A-69. Option 64, DVB-T/H Signal Analyzer, Frequency Accuracy for –50 dBm Reference Level
Channel Reference Level Frequency Error Specification
21 –50 dBm Hz ± 0.3 Hz
45 –50 dBm Hz ± 0.3 Hz
69 –50 dBm Hz ± 0.3 Hz
Table A-70. Option 64, DVB-T/H Signal Analyzer, Residual MER Pre Amp Off
Channel Total MER Specification
21 dB ≥ 42 dB
45 dB ≥ 42 dB
69 dB ≥ 42 dB
Table A-71. Option 64, DVB-T/H Signal Analyzer, Residual MER Pre Amp On
Channel Total MER Specification
21 dB ≥ 37 dB
45 dB ≥ 37 dB
69 dB ≥ 37 dB
