Anritsu MT8212E - E1 Analyzer Verification, Option 52

A-5 Test Records for Options Verification
A-40 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
E1 Analyzer Verification, Option 52
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-56. Option 52, E1 Frequency Clock
Measurement Measured Value Specification
Internal Clock Error ±5ppm
Recovered Clock Frequency 204790 to 2048010 Hz
Table A-57. Option 52, E1 Transmitted Level Voltage
Measurement Measured Value Specification
120 ohm (RJ48 Interface) 5.4 to 6.6 Vp-p
75 ohm (BNC Interface) 4.2 to 5.2 Vp-p
Table A-58. Option 52, E1 Transmitted Level Vpp Reading
Measurement Vpp Reading Specification
120 ohm (RJ48 Interface) 5.4 to 6.6 Vp-p
75 ohm (BNC Interface) 4.2 to 5.2 Vp-p
