Anritsu MT8212E - T1;T3 Analyzer Verification, Option 53

A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-41
Test Records for Options Verification (continued)
T1/T3 Analyzer Verification, Option 53
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-59. Option 53, T1/T3 Frequency Clock
Measurement Measured Value Specification
Internal Clock Error ±5ppm
Recovered Clock Frequency 1543992 to 1544008 Hz
Table A-60. Option 53, T1 Transmitted Level Voltage
Measurement Measured Value Specification
Tx LBO: 0 dB 4.8 to 7.2 Vp-p
Tx LBO: –7.5 dB 1.9 to 3.1 Vp-p
Tx LBO: –15 dB 0.5 to 1.7 Vp-p
Table A-61. Option 53, T1 Transmitted Level Vpp Reading
Measurement Vpp Reading Specification
Tx LBO: 0 dB 4.8 to 7.2 Vp-p
Tx LBO: –7.5 dB 1.9 to 3.1 Vp-p
Tx LBO: –15 dB 0.5 to 1.7 Vp-p
Table A-62. Option 53, T3 Frequency Clock
Measurement Measured Value Specification
Internal Clock Error ±5ppm
Recovered Clock Frequency 44735776 to 44736224 Hz
