Anritsu MT8212E - WCDMA;HSDPA Signal Analyzer Verification, Options

A-5 Test Records for Options Verification
A-34 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
WCDMA/HSDPA Signal Analyzer Verification, Options 44, 45, 65,
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-42. Option 44, Sensor A and B Reading Components Characterization Table
Frequency
PMA.10
(dBm)
PMB.10
(dBm)
Δ1
(dBm)
PMA.10C
(dBm)
PMA.20
(dBm)
ATT.10
(dB)
881.5 MHz
Table A-43. Option 44, Power Level Setting Components Characterization Table
Frequency
MG3700A.10 Setting
(dBm)
MG3700A.20 Setting
(dBm)
PMA.10
(dBm)
PMA.20
(dBm)
881.5 MHz
Table A-44. Option 44, WCDMA Absolute Power Accuracy
Test Level Measured Power Error Specification
+20 dBm dBm dB ± 1.25 dB
+10 dBm dBm dB ± 1.25 dB
–10 dBm dBm dB ± 1.25 dB
–20 dBm dBm dB ± 1.25 dB
Table A-45. Option 44, WCDMA Occupied Bandwidth (OBW)
Frequency Power Meter Reading OBW Specification
881.5 MHz dBm 4.2 MHz ± 100 kHz
1962.5 MHz dBm 4.2 MHz ± 100 kHz
2680.5 MHz dBm 4.2 MHz ± 100 kHz
