A-2 Test Records for Spectrum Analyzer Verification
A-12 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Spectrum Analyzer Verification (Continued)
Displayed Average Noise Level (DANL) (continued)
Third Order Intercept (TOI) Verification
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-12. Spectrum Analyzer DANL with Pre Amp On
Start Freq Stop Freq RBW VBW
Measured Value at
100 kHz RBW
Calculated for
1 Hz RBW Specification
10 MHz 2.4 GHz 100 kHz 1 kHz dBm dBm ≤ –157 dBm
2.4GHz 4.0GHz 100kHz 1kHz dBm dBm ≤ –154 dBm
4.0GHz 5.0GHz 100kHz 1kHz dBm dBm ≤ –150 dBm
5.0GHz 6.0GHz 100kHz 1kHz dBm dBm ≤ –143 dBm
Table A-13. Third Order Intercept (TOI) Verification
Frequency Measured Max Value
Calculated TOI
TOI = –20 + [(–20 - max) / 2] Specification
800 MHz dBm dBm ≥ 16 dBm
2400 MHz dBm dBm ≥ 20 dBm
