Anritsu MT8212E - Test Records for Power Meter Verification; Power Meter Level Accuracy

A-4 Test Records for Power Meter Verification
A-14 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
A-4 Test Records for Power Meter Verification
Power Meter Level Accuracy
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-16. Characterization Chart for Power Meter Verification
Test Power Level at 50 MHz Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Test Power Level at 4000 MHz Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Test Power Level at 6000 MHz Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Table A-17. Internal Power Meter Accuracy Verification
Frequency Input Power Measured Values Specification
50 MHz 0 dBm dBm ± 1.25 dB
–50 dBm dBm ± 1.25 dB
4.0 GHz 0 dBm dBm ± 1.25 dB
–50 dBm dBm ± 1.25 dB
6.0 GHz 0 dBm dBm ± 1.50 dB
–50 dBm dBm ± 1.50 dB
