Chapter 4 — File Management
4-1 Introduction
This chapter will review the file management features of the Cell Master and detail the
File menu. The submenus under this menu allow the user to save, recall, copy, and delete files
in internal memory or an external USB flash drive.
4-2 Managing Files
Press the Shift key then the File (7) key on the numeric keypad to list the File menu. Follow
the additional steps below.
Save Files
Set the Save Location
Press Save then the Change Save Location submenu keys and select the location to save files.
You can save files to the internal memory or to an external USB flash drive. You can also
create new folders. If an external USB flash drive is connected or disconnected, press Refresh
Directories to update the location tree. Press the Set Location key to store the save location.
Save Measurement As
The Save Measurement As key is used to quickly save measurements with a specific file
name. The Cell Master saves the measurement with the latest file name that was used to
save a measurement and with a number that is automatically incremented and appended to
the end of the file name. For instance, if the last measurement was saved with the name
System Return Loss, Save Measurement As saves the next measurement as System Return
Loss_#1, System Return Loss_#2 etc. The file name used can be changed using the Save
dialog box (Figure 4-1).
Save a Measurement
Press the Save Measurement key and enter the name for the measurement file. The
measurement file type defaults to DAT format, but measurements also can be saved in VNA
format (you must select VNA before saving). Note that both DAT and VNA file types support
full data point resolution (up to 2204), but older Anritsu PC software programs may support
up to only 551 points. While files may appear with less points, full point resolution is
available from these files in Line Sweep Tools. Measurements may be saved as other file
types, such as JPEG. You may save Setup files (STP), but note that Setup files DO NOT
contain measurement data.
Save a Setup
Press the Save submenu key, type a name for the setup file, confirm that the file type is Setup
using the Change Type key or the touchscreen and press Enter to save.
Note
When navigating through the File menu, pressing the Esc key will return to the
previous menu.
