System Operations 5-3 System Menu
Cell Master UG PN: 10580-00250 Rev. K 5-5
System Options 2/2 Menu
Key Sequence: Shift, System (8) > System Options > More
Remote Access Password
This function is valid only with Master Software Tools (MST) v2.21.1 or later. After setting
the password, reboot the instrument (normal power OFF then ON) to provide remote access
security. Only one user then has access at any one time.
The password is first set into the instrument, then used in MST. When prompted in MST,
enter the password into the password text box. The password text box shown in Figure 5-5
may differ from the text box that is displayed on your instrument.
The password can be removed or reset by a Master Reset, by a Factory Default reset, or by a
firmware update (which includes a restart).
Share CF & Pwr Offset
All Modes Not Shared: Press this submenu key to toggle the setting to
All Modes or to Not Shared. Select All Modes to have the current center
frequency setting and power offset setting carried over when changing
measurement modes. This function is not applicable to measurements that do
not have a center frequency or power offset setting or to measurements in
which the current center frequency or power offset setting is outside the range
of the new measurement.
Set Remote Access Password: Press this submenu key to open the
Password text box (Figure 5-5) and Text Entry menu. Type in the desired
password. Upper case and lower case letters and the symbols - _ + . are
the allowed password characters. Press Enter to save or Esc to cancel.
Back: Press this submenu key to return to the “System Options Menu”
on page 5-4.
Figure 5-4. System Options Menu 2/2)
Warning Do not use SCPI commands with this feature.
Figure 5-5. Remote Access Password Text Box
Back
System Options 2/2
Share CF &
Pwr Offset
All Modes Not Shared
Set
Remote Access
Password
Press Shift for Caps
Use arrow keys to navigate cursor within file name
Enter to Save
Password
