A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-29
Test Records for Options Verification (continued)
ISDB-T SFN Verification, Option 32 (continued)
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-36. ISDB-T SFN Analyzer DANL with Pre Amp Off
Channel Frequency Ref Level Measured Value Specification
13 473.14285714 MHz –25 dBm dBm ≤ –70 dBm
38 623.14285714 MHz –25 dBm dBm ≤ –70 dBm
62 767.14285714 MHz –25 dBm dBm ≤ –70 dBm
Table A-37. ISDB-T SFN Analyzer DANL with Pre Amp On
Channel Frequency Ref Level Measured Value Specification
13 473.14285714 MHz –50 dBm dBm ≤ –90 dBm
38 623.14285714 MHz –50 dBm dBm ≤ –90 dBm
62 767.14285714 MHz –50 dBm dBm ≤ –90 dBm
To Next Page
