3. Press the Bottom submenu key and use the keypad, rotary knob, or the arrow keys to
edit the bottom scale value. Press Enter to set.
Turn on Markers
1. Press the Marker main menu key.
2. Press the Marker 1 2 3 4 5 6 submenu key and select the marker number 1 button using
the touch screen. The underlined number on the Marker submenu key indicates the
active marker.
3. Use the arrow keys, the keypad, or the rotary knob to move the marker. The current
value for the selected marker is shown above the upper-left corner of the graph. It is
also possible to drag the marker using the touch screen.
4. Delta Markers are available for each of the six reference markers. For the selected
marker, Toggle the Delta On/Off submenu key to turn on the Delta marker.
Peak/Valley Auto Markers
When making Return Loss and VSWR measurements, the Peak/Valley Auto feature can be
used to automatically turn on Marker 1 to peak, Marker 2 to valley, and display M1 and M2
in the Marker Table. This feature is not available for DTF measurements.
1. Press the Marker main menu key.
2. Press the Peak/Valley Auto key.
Note
For Amplitude in Smith Chart measurements, refer to “Smith Chart” in the Cable &
Antenna Measurement Guide listed in Appendix A.
