Anritsu MT8212E - Test Records for Spectrum Analyzer Verification; Frequency Accuracy Verification; Single Side Band (SSB) Phase Noise Verification; Spurious Response (Second Harmonic Distortion) Verification

A-2 Test Records for Spectrum Analyzer Verification
A-2 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
A-2 Test Records for Spectrum Analyzer Verification
Frequency Accuracy Verification
Single Side Band (SSB) Phase Noise Verification
Spurious Response (Second Harmonic Distortion) Verification
MT821_E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-1. Spectrum Analyzer Frequency Accuracy
Frequency Measured Value Deviation Specification
1 GHz GHz kHz ± 1.5 kHz (± 1.5 ppm)
3.9 GHz GHz kHz ± 5.85 kHz (± 1.5 ppm)
5.9 GHz GHz kHz ± 8.85 kHz (± 1.5 ppm)
Table A-2. Spectrum Analyzer SSB Phase Noise Verification
Frequency Measured Value Calculated Value Specification
10 kHz dBc/Hz dBc/Hz ≤ – 100 dBc/Hz
100 kHz dBc/Hz dBc/Hz ≤ – 105 dBc/Hz
1 MHz dBc/Hz dBc/Hz ≤ –115dBc/Hz
Table A-3. Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Frequency Measured Value 2nd Harmonic Distortion Specification
50.1 MHz
100.2 MHz dBc ≤ –56 dBc
