Anritsu MT8212E - GSM;GPRS;EDGE Signal Analyzer Verification, Options 40 and 41

A-5 Test Records for Options Verification
A-30 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
GSM/GPRS/EDGE Signal Analyzer Verification, Options 40 and 41
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-38. Option 40 GSM/GPRS/EDGE RF Measurements
Error Type Measured Value Specification
At 850 MHz, –10 dBm Level, TCH Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 850 MHz, –50 dBm Level, TCH ALL Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 1800 MHz, –10 dBm Level, TCH ALL Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 1800 MHz, –50 dBm Level, TCH Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 850 MHz, –10 dBm Level, DL_MCS-9_1SLOT Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 850 MHz, –50 dBm Level, DL_MCS-9_4SLOT Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 1800 MHz, –10 dBm Level, DL_MCS-9_4SLOT Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern
Burst Power Error dB ±1.5 dB
Frequency Error Hz ±10 Hz
