A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-31
Test Records for Options Verification (continued)
GSM/GPRS/EDGE Signal Analyzer Verification, Options 40 and 41 (continued)
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-39. Option 41 GSM/GPRS/EDGE Demodulator
Measurement Measured Value Specification
At 850 MHz, –10 dBm Level, TCH Pattern
Phase Err RMS (Deg) Deg ≤ 1Deg
At 850 MHz, –50 dBm Level, TCH ALL Pattern
Phase Err RMS (Deg) Deg ≤ 1Deg
At 1800 MHz, –10 dBm Level, TCH ALL Pattern
Phase Err RMS (Deg) Deg ≤ 1Deg
At 1800 MHz, –50 dBm Level, TCH Pattern
Phase Err RMS (Deg) Deg ≤ 1Deg
At 850 MHz, –10 dBm Level, DL_MCS-9_1SLOT Pattern
EVM RMS % ≤ 2.5%
At 850 MHz, –50 dBm Level, DL_MCS-9_4SLOT Pattern
EVM RMS % ≤ 2.5%
At 1800 MHz, –10 dBm Level, DL_MCS-9_4SLOT Pattern
EVM RMS % ≤ 2.5%
At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern
EVM RMS % ≤ 2.5%
