Anritsu MT8212E - ISDB-T and BER Verification, Options 30 and 79

A-5 Test Records for Options Verification
A-16 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
ISDB-T and BER Verification, Options 30 and 79
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-20. ISDB-T Signal Analyzer Frequency Accuracy
Channel Frequency
Ref
Level
Pre Amp Off
Freq Error Spec.
Ref
Level
Pre Amp On
Freq Error Spec.
13 473.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
38 623.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
62 767.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
Table A-21. ISDB-T Signal Analyzer Frequency Lock Range
Channel Frequency Measured Frequency Error Specification
13 473.23285714 MHz Hz 90,000 ± 0.3 Hz
13 473.05285714 MHz Hz –90,000 ± 0.3 Hz
Table A-22. Level Accuracy Verification, AT(–10)
Frequency
(Channel)
Sensor A
Reading
Sensor B
Reading ΔAB(–10)
MN63A Attenuation
Reading, AT(–10)
473.14285714 MHz
(Ch 13)
623.14285714 MHz
(Ch 38)
767.14285714 MHz
(Ch 62)
