Anritsu MT8212E - T1;T3 Analyzer Verification, Option 53; TD-SCDMA Signal Analyzer Verification, Options 60 and 61

A-5 Test Records for Options Verification
A-42 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
T1/T3 Analyzer Verification, Option 53 (continued)
TD-SCDMA Signal Analyzer Verification, Options 60 and 61
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-63. Option 53, T3 Transmitted Level Voltage
Measurement Measured Value Specification
DSX 0.72 to 1.7 Vp-p
LOW 0.72 to 1.7 Vp-p
Table A-64. Option 53, T3 Transmitted Level Vpp Reading
Measurement Vpp Reading Specification
DSX 0.72 to 1.7 Vp-p
LOW 0.72 to 1.7 Vp-p
Table A-65. Option 60, 61, TD-SCDMA Verification (at 2010 MHz, –45 dBm Level, TD-SCDMA)
Measurement Measured Value Specification
Channel Power (Error) ±1.5dB
Frequency Error ±10Hz
Tau ±0.2µs
