Anritsu MT8212E - EVDO Signal Analyzer Verification, Options 62 and 63

A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-43
Test Records for Options Verification (continued)
EVDO Signal Analyzer Verification, Options 62 and 63
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-66. Option 62, EVDO RF Measurements
Measurement Measured Value Specification
At 870.03 MHz, –50 dBm Level, 921.6kps 8-PSK Modulation
Channel Power Error dB ± 1.5 dB
At 1930.05 MHz, 0 dBm Level, 38.4kps QPSK Modulation
Channel Power Error dB ± 1.5 dB
At 1930.05 MHz, –50 dBm Level, 2457.6kps 16-QAM Modulation
Channel Power Error dB ± 1.5 dB
At 1930.05 MHz, –50 dBm Level, Idle Slot
Channel Power Error dB ± 1.5 dB
At 870.03 MHz, –10 dBm Level, Idle Slot
Channel Power Error dB ± 1.5 dB
