A-5 Test Records for Options Verification
A-44 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
EVDO Signal Analyzer Verification, Options 62 and 63 (continued)
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-67. Option 63, EVDO Demodulator
Measurement Measured Value Specification
At 870.03 MHz, –50 dBm Level, 921.6kps 8-PSK Modulation
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 1930.05 MHz, 0 dBm Level, 38.4kps QPSK Modulation
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 1930.05 MHz, –50 dBm Level, 2457.6kps 16-QAM Modulation
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 1930.05 MHz, –50 dBm Level, Idle Slot
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 870.03 MHz, –10 dBm Level, Idle Slot
Frequency Error Hz ± 10 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
