Anritsu MT8212E - Spectrum Analyzer Absolute Amplitude Accuracy Verification

A-2 Test Records for Spectrum Analyzer Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-5
Test Records for Spectrum Analyzer Verification (Continued)
Spectrum Analyzer Absolute Amplitude Accuracy Verification
Table A-5. Spectrum Analyzer 50 MHz Absolute Amplitude Accuracy Setup Table
Test Power Level at 50 MHz Required Sensor B Reading
0dBm dBm
–4 dBm dBm
–10 dBm dBm
–14 dBm dBm
–20 dBm dBm
–24 dBm dBm
–30 dBm dBm
–34 dBm dBm
–40 dBm dBm
–44 dBm dBm
–50 dBm dBm
Table A-6. Spectrum Analyzer 50 MHz Absolute Amplitude Accuracy
Input Power Level Reference Level Input Atten. Level Measured Reading Specification
0 dBm 10 dBm 30 dB dBm ± 1.25 dB
–4 dBm 10 dBm 30 dB dBm ± 1.25 dB
–10 dBm 0 dBm 20 dB dBm ± 1.25 dB
–14 dBm 0 dBm 20 dB dBm ± 1.25 dB
–20 dBm –10 dBm 10 dB dBm ± 1.25 dB
–24 dBm –10 dBm 10 dB dBm ± 1.25 dB
–30 dBm –20 dBm 0 dB dBm ± 1.25 dB
–34 dBm –20 dBm 0 dB dBm ± 1.25 dB
–40 dBm –30 dBm 0 dB dBm ± 1.25 dB
–44 dBm –30 dBm 0 dB dBm ± 1.25 dB
–50 dBm –40 dBm 0 dB dBm ± 1.25 dB
Turn Pre-Amp On (for the below measurement)
-44 dBm -40 dBm 10 dB dBm ± 1.25 dB
-50 dBm -45 dBm 5 dB dBm ± 1.25 dB
