Anritsu MT8212E - Mobile Wimax Residual EVM and Frequency Error Tests (Option 67)

A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-53
Test Records for Options Verification (continued)
Mobile WiMAX Signal Analyzer Verification, Options 66 and 67 (continued)
Mobile WiMAX Residual EVM and Frequency Error Tests (Option 67)
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-87. Option 67, Mobile WiMAX Residual EVM (10 MHz Bandwidth and 10 ms Frame Length)
Frequency
(MHz) Power (dBm) BW (MHz) EVM (rms) Specification
2600.5 –15 10 % ≤ 3.0%
2600.5 –50 10 % ≤ 3.0%
3600.5 –15 10 % ≤ 3.0%
3600.5 –50 10 % ≤ 3.0%
Table A-88. Option 67, Mobile WiMAX Frequency Error (10 MHz Bandwidth and 10 ms Frame Length)
Frequency
(MHz) Power (dBm) Freq Error Specification
2600.5 –50 Hz ± 52.01 Hz
3600.5 –50 Hz ± 72.01 Hz
Table A-89. Option 67, Mobile WiMAX Residual EVM (5 MHz Bandwidth and 5 ms Frame Length)
Frequency
(MHz) Power (dBm) BW (MHz) EVM (rms) Specification
2600.5 –15 5 % ≤ 3.0%
2600.5 –50 5 % ≤ 3.0%
3600.5 –15 5 % ≤ 3.0%
3600.5 –50 5 % ≤ 3.0%
Table A-90. Option 67, Mobile WiMAX Frequency Error (5 MHz Bandwidth and 5 ms Frame Length)
Frequency
(MHz) Power (dBm) Freq Error Specification
2600.5 –50 Hz ± 52.01 Hz
3600.5 –50 Hz ± 72.01 Hz
