A-2 Test Records for Spectrum Analyzer Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-11
Test Records for Spectrum Analyzer Verification (Continued)
Residual Spurious Response Verification
Displayed Average Noise Level (DANL)
Table A-9. Spectrum Analyzer Residual Spurious with Preamp Off
Start Freq. Stop Freq. RBW VBW Measured Values Specification
10MHz 50MHz 1kHz 300Hz dBm ≤ –90dBm
50 MHz 2.0 GHz 3 kHz 10 kHz dBm ≤ –90dBm
2.0GHz 4.0GHz 1kHz 1kHz dBm ≤ –90dBm
4.0GHz 5.0GHz 1kHz 3kHz dBm ≤ –90dBm
5.0GHz 5.2GHz 1kHz 1kHz dBm ≤ –90dBm
5.2GHz 5.7GHz 300Hz 3kHz dBm ≤ –90dBm
5.7GHz 5.9GHz 300Hz 3kHz dBm ≤ –90dBm
5.9 GHz 6.0 GHz 1 kHz 100 Hz dBm ≤ –90dBm
Table A-10. Spectrum Analyzer Residual Spurious with Preamp On
Start Freq. Stop Freq. Measured Values Specification
10 MHz 1.0 GHz dBm ≤ –90dBm
1.0 GHz 4.0 GHz dBm ≤ –90dBm
4.0 GHz 6.0 GHz dBm ≤ –90dBm
Table A-11. Spectrum Analyzer DANL with Pre Amp Off
Start Freq Stop Freq RBW VBW
Measured Value at
100 kHz RBW
Calculated for
1 Hz RBW Specification
10 MHz 2.4 GHz 100 kHz 1 kHz dBm dBm ≤ –141 dBm
2.4 GHz 4.0 GHz 100 kHz 1 kHz dBm dBm ≤ –137 dBm
4.0 GHz 5.0 GHz 100 kHz 1 kHz dBm dBm ≤ –134 dBm
5.0 GHz 6.0 GHz 100 kHz 1 kHz dBm dBm ≤ –126 dBm
