A-2 Test Records for Spectrum Analyzer Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-3
Test Records for Spectrum Analyzer Verification (Continued)
Resolution Bandwidth Accuracy Verification
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-4. Spectrum Analyzer Resolution Bandwidth Accuracy
BW Setting Span VBW Lower Limit Measured Values Upper Limit
3MHz 4.5MHz Auto 2.7MHz Hz 3.3MHz
1 MHz 1.5 MHz Auto 900 kHz Hz 1.1 MHz
300 kHz 450 kHz Auto 270 kHz Hz 330 kHz
100 kHz 150 kHz Auto 90 kHz Hz 110 kHz
30 kHz 45 kHz Auto 27 kHz Hz 33 kHz
10 kHz 15 kHz Auto 9 kHz Hz 11 kHz
3kHz 4.5kHz Auto 2.7kHz Hz 3.3kHz
1kHz 2kHz Auto 900Hz Hz 1.1kHz
300 Hz 450 Hz Auto 270 Hz Hz 330 Hz
100 Hz 150 Hz Auto 90 Hz Hz 110 Hz
30Hz 50Hz 3Hz 27Hz Hz 33Hz
10 Hz 30 Hz 3 Hz 9 Hz Hz 11 Hz
Below settings are used only for units with 20 MHz IF BW Available (found in System Status menu)
3Hz 10Hz 1Hz 2.7Hz 3.3Hz
1Hz 10Hz 1Hz 0.9Hz 1.1Hz
