A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-33
Test Records for Options Verification (continued)
CDMA Signal Analyzer Verification, Options 42 and 43 (continued)
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-41. Option 43 cdmaOne and CDMA2000 1xRTT Demodulator
Measurement Measured Value Specification
At 870.03 MHz, –30 dBm Level, cdmaOne
Frequency Error Hz ± 10 Hz
Rho 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 1930.05 MHz, –30 dBm Level, cdmaOne
Frequency Error Hz ± 10 Hz
Rho 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 1930.05 MHz, –30 dBm Level, CDMA2000
Frequency Error Hz ± 10 Hz
Rho 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
At 870.03 MHz, –30 dBm Level, CDMA2000
Frequency Error Hz ± 10 Hz
Rho 0.99 ≤ x ≤ 1
Tau µs ± 1 µs
