A-38 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
Test Records for Options Verification (continued)
Fixed WiMAX Signal Analyzer Verification, Options 46 and 47 (continued)
Fixed WiMAX Signal Analyzer Option Verification (Option 47)
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-51. Option 47, Fixed WiMAX Residual EVM
Frequency Power BW EVM (RMS) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
2600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
3600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
3600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
5600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
5600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
Table A-52. Option 47, Fixed WiMAX Frequency Error
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 182 Hz
5600.5 MHz –50 dBm Hz ± 392 Hz
