A-2 Test Records for Spectrum Analyzer Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-7
Test Records for Spectrum Analyzer Verification (Continued)
Spectrum Analyzer Absolute Amplitude Accuracy Verification (continued)
MT821_E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-8. Spectrum Analyzer Absolute Amplitude Accuracy Across Frequency (1 of 4)
Freq (MHZ)
Input Power
(dBm)
Reference
Level Setting
(dBm)
Atten. Level
Setting (dB)
Pre-Amp
Setting
Marker 1 Reading
(dBm)
Spec
(dB)
10.1 –50 –40 15 On ±1.25
–30 –20 0 Off ±1.25
–30 –20 5 Off ±1.25
–30 –20 10 Off ±1.25
–30 –20 20 Off ±1.25
–2 0 30 Off ±1.25
–2 0 40 Off ±1.25
–2 0 50 Off ±1.25
–2 0 55 Off ±1.25
50 –50 –40 15 On ±1.25
–30 –20 0 Off ±1.25
–30 –20 5 Off ±1.25
–30 –20 10 Off ±1.25
–30 –20 20 Off ±1.25
–2 0 30 Off ±1.25
–2 0 40 Off ±1.25
–2 0 50 Off ±1.25
–2 0 55 Off ±1.25
