A-5 Test Records for Options Verification
MT8212E and MT8213E MM PN: 10580-00255 Rev. J A-51
Test Records for Options Verification (continued)
Table A-81. Option 78, DVB-T/H SFN, Level Accuracy for Channel 45, 666 MHz
Table A-82. Option 78, DVB-T/H SFN, Level Accuracy for Channel 69, 858 MHz
MT821_E Firmware Revision: _______________ Operator: _______________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Test
Level
(dBm)
Ref Level
Pre Amp
Off(dBm)
Pre Amp Off
RefLevel Pre
Amp On (dBm)
Pre Amp On
Specification (dBm)
Measured
Level (dBm)
Measured
Level (dBm)
–10 –10 -10 -10 ± 2.0
–20 –10 -10 -20 ± 2.0
–30 –10 -10 -30 ± 2.0
–40 –10 -10 -40 ± 2.0
Test
Level
(dBm)
Ref Level
Pre Amp
Off(dBm)
Pre Amp Off
RefLevel Pre
Amp On (dBm)
Pre Amp On
Specification (dBm)
Measured
Level(dBm)
Measured
Level (dBm)
–10 –10 -10 -10 ± 2.0
–20 –10 -10 -20 ± 2.0
–30 –10 -10 -30 ± 2.0
–40 –10 -10 -40 ± 2.0
Table A-83. Option 78, DVB-T/H SFN Analyzer DANL with Pre Amp Off
Frequency Ref Level Measured Value Specification
474MHz –25dBm dBm ≤ –69 dBm
666MHz –25dBm dBm ≤ –69 dBm
858MHz –25dBm dBm ≤ –69 dBm
Table A-84. Option 78, DVB-T/H SFN Analyzer DANL with Pre Amp On
Frequency Ref Level Measured Value Specification
474MHz –50dBm dBm ≤ –89 dBm
666MHz –50dBm dBm ≤ –89 dBm
858MHz –50dBm dBm ≤ –89 dBm
