Anser A1 - Figure 1-3. Initial Setup

To Next Page

To Previous Page

ANSER CODING INC. 4 A1 User Interface

After creating the admin account, the A1 wizard will guide you to configure the system date time and the necessary

settings to start A1, as seen in the following figure. Press the drop-down buttons “ ” in Time Zone to select the area

and the city you are at.

Figure 1-3. Initial Setup – System Time

Click Next and OK to complete more initial settings following A1 Wizard.

Select an area

and a city.
