ANSER CODING INC. 83 A1 Operation
Table 3-4. I/O Edit – Logical Operand Definition
Parameter Definition
AND AND is a logical operand where an A event and a B event both become “TRUE”; In
other words, it is the logical conjunction of the selected events.
OR OR is a logical operand where either an A event or of a B event become “TRUE”; In
other words, it is the logical (inclusive) disjunction of the selected events.
XOR XOR is a logical operand where an A event is “TRUE” and a B event is “FALSE” or an
A event is “FALSE” and a B event is “TRUE”; In other words, it is the logical
exclusiveness of the selected events. (Exclusive disjunction.)
Please refer to the following table for the action that is triggered when events are true.
Table 3-5. I/O Edit – Action List
Action Definition
Print Job - Print Stop: Stop production line.
- Print Start: Start production line.
- Purge: Enables pre-purge printhead settings.
- Reset Counter: Reset object message counters (item, box and lot).
Output A1 alarm port (M8 6-pin). Please refer to A1 Technical Specifications V0.1.
- Alarm Green: Set the output pin #6 signal status.
- Alarm Yellow: Set the output pin #4 signal status.
- Alarm Red: Set the output pin #2 signal status.
- Alarm Buzzer: Set the output pin #5 signal status.
