ANSER CODING INC. 25 A1 User Interface

Press and hold on a text/object to change its position. A pair of horizontal or vertical arrows will show moving direction.

Figure 1-27. Add Object – Hold to Adjust Position

Or use Clipboard “ ” at the bottom tool bar to adjust or key-in the desired position of selected object.

Figure 1-28. Add Object – Adjust Position in Clipboard

Set the distance of

each arrow key press.

Arrow keys
