ANSER CODING INC. 87 Troubleshooting

4.2.3 Printer LED Status

Table 4-4. Printer LED Status and Definition

Event

LED Action

Note

Green Yellow Red

Power ON ON OFF - -

Power OFF OFF OFF OFF -

Printing Flashing OFF - -

Ink Low - ON - -

Cartridge Error / Ink Empty ON OFF ON No cartridges or the

country code / area code

does not match.

Top Cover / Cartridge Latch Open ON OFF ON -
