Anser A1 - Figure 1-57. Scan & Select - Enable Rule 1; Table 1-10. Scan & Select Settings Definition

ANSER CODING INC. 52 A1 User Interface
Figure 1-57. Scan & Select – Enable Rule 1
Table 1-10. Scan & Select Settings Definition
Parameter Definition
Rule Index for the scan and select conditions.
Production Line Select the production line where users want to assign the selected message.
Note: Only one production line can be selected.
Message Name Select the message that will be selected if the Data Key matches the scan data.
Data Key The data that is expected to be contained in the scan stream.
Assigned Station Select one or two stations where users assign the message.
Enable Check to enable the rule conditions.
