Appendix

Printer Maintenance

- Before powering up, make sure all the components are connected.

- Before shutting down, please remove the cartridge, and shutdown system from UI shutdown button, and then press

the power switch behind the printer prior to disconnecting any of the components.

Printer Firmware Upgrade

A1 software can be upgraded by USB.

STEP 1: Before it starts, please make sure that the USB is formatted as FAT32 and the size of the partition is under 32GB.

STEP 2: Create a new folder within the USB and name it as auprn.

STEP 3: Copy the software upgrade file into the USB://auprn folder.

Note: Please remove ink cartridge(s) before firmware upgrade for A1 printer.

A1FW_V02.000.00.013_20230116#39528fa9_ac450fd2.bin
