ANSER CODING INC. 12 A1 User Interface

STEP 4: After saving the edited message, a notification appears as the following Figure 1-14 shows. Press OK to start

printing.

Figure 1-14. Initial Setup – Select from Template (4)

Note:

Close A1

dust cover before hitting the Start “ ” botton to ensure that cartridge latch

remains closed.
