ANSER CODING INC. 72 A1 Operation
Figure 3-2. Variable Input Sources Diagram
Table 3-1. Variable Input Methods
Variable Table Variable Buffer Excel Files
Methods
to Edit
1. PC Software (Message Pro X)
2. Printer UI
3. Net Protocol over Ethernet
(0xCA)
4. USB
1. Net Protocol over Ethernet
(0xCF, 0xCB, 0xCC)
1. PC Software (Message Pro X)
Note Variable source setup as
“Default”.
Variable source setup as
“External”.
Variable source setup as
“Database”.
3.1.1 Internal Variable Table
There is a total of 20 variables per table that can be defined and kept in an A1 printer. Each of the variables can hold up
to 100 alphabets (100 bytes). Message editor is full Unicode supported in UTF-8 format.
3.1.2 Excel Files or Database
Variable objects are able to take imported .csv file extensions as a source. When a print job starts, users have the option
to preview and choose which entry or row they would like to start.
