ANSER CODING INC. 50 A1 User Interface
The data is contained into the variable objects which later can be used when creating a message. Scan & Print also
permits to split the data into parts according to position and length of the serial data.
Table 1-9. Scan & Print Settings Definition
Parameter Definition
Device - ttyS01 stands for RS-232 and ttyS04 for RS-485 when no device is connected or the
scanner is not setup as virtual COM or CDC.
- ttyACM0 or ttyUSB0 will appear when A1 detects the serial device.
Number of Scan - Perform multiple scans, data is stored to variable1, variable2, up to 20.
- In the upper right corner of the home page, Scan&Print button “ ” will show
"Current Scan Number / Number of Scan”. Press it to see the scan data.
Note: If there’s more than 1 scan, position and length for serial data is not supported.
Number of Print Set a count for how many times to print the scan data.
0: Unlimited number of prints.
1-50: Limited number of prints.
Variable File Off: Doesn’t save to internal variable table. Works as a buffer.
Variable Table List: Select one table to save the data.
Position Set the starting position from where to start capturing part of data stream.
Length Set the size of how many characters the system wants to capture from the data stream.
Importing Data A preview of the scan data before setting position and length.
Formatting Data View data after it is split into multiple variables according to position and length.
