ANSER CODING INC. 13 A1 User Interface

Import File

STEP 1: Connect a USB and press Import File to choose messages stored in it.

Figure 1-15. Initial Setup – Import File (1)

STEP 2: Double-click the folder previously stored and select a desired message. Press Next to complete the settings.

Figure 1-16. Initial Setup – Import File (2)

Press to import.
