ANSER CODING INC. 85 Troubleshooting

4 Troubleshooting

4.1 Fault Messages and Warnings

4.1.1 Ink Cartridge Fault

Table 4-1. Ink Cartridge Fault and Description

Fault Description

No Cartridge It normally happens when no cartridge is detected. Additionally, this could happen

when chip failure or abnormal cartridge latch happens.

Ink Type Not Supported The ink type is not supported in the current software version or printer model.

Ink Capacity Not Supported Ink cartridge volume is not supported in the current software version or printer

model.

Ink Color Not Supported The ink color is not supported in the current software version.

Ink Empty Ink cartridge is empty. Please change a new cartridge.

Ink Low The ink level is low (with 5% left) or lower than the custom trigger value.

EDC Not Match Either the country code, area code or both codes don’t match printer EDC.
