ANSER CODING INC. 21 A1 User Interface

1.4.1.1 Add Object: Text

STEP 1: In Add Object page, press Text “ ” and the following page will show. Use buttons below to create a

template “ ”, to edit selected template “ ”, or to delete a text template “ ”. After editing your text

template, press OK.

Figure 1-21. Add Object – Select a Text Template

Preview

Select a template.
