ANSER CODING INC. 37 A1 User Interface
1.4.2 Message Related Settings
Table 1-6. Message Related Settings
Option Description
Message Name Default system message or custom input by the users.
Printouts Set a maximum number of prints for the message. The value zero means no limit.
Line Mode Add editing guidelines to message editor. It is useful when creating a message with
content spread in multiple lines.
Delay It represents the distance (unit: mm or inch) from the sensor to the printhead
cartridge nozzle, i.e., the distance between product detected by the sensor and the
desired spot of a message. Each individual message can have its own delay value.
Please refer to Figure 1-40. When it is enabled, it overwrites Print Station Delay (see
Figure 1-47).
Direction Message printing direction, as a default, follows print station Print Direction.
Upside Down Default: Follow the print station setting.
Normal: Overwrite the upside-down printing settings in the print station.
Upside Down: Print the message upside down.
Height Message height based on the printhead height.
Width Display the total width of the current message.
Fixed Width Adjusts the width of the entire message when the width changes due to variable
content.
Full Text Reduces the blue area (empty area) surrounding message objects.
Figure 1-40. Message Delay
