ANSER CODING INC. 60 A1 User Interface

1.6.6 About Printer

Navigate to Menu “

” > Settings “ ” > About (refer to Figure 1-63 below.) to see detailed printer information.

Figure 1-63. The About Page

The About page provides information about software and hardware version of the printer as well as information about

printheads and ink cartridges.

Options to reset the system to factory default “ ”, to restore the system from a backup “ ”, and to import/export

“ ” can all be found in this page.
