STwrench User Guide Multistage
9836 4134 01 Edition 2.9 141 (326)
See the Setting the source for Pset/Multistage/Job selection and Identifier chapters for more
information.
If the source program is the not the Barcode, but a barcode reading is required for the Pset, the following
message is shown to indicate that the bar code is required:
If the source program is the not the TAG, but a specific end-fitting tool number is required for the
Pset, the following message is shown in the event of the specified tool not being inserted into the
wrench head:
During Multistage execution, the wrench display shows torque and possibly angle values, and the
tightening direction:
During Multistage execution, pressing the CL button on the wrench display will abort the Multistage, and
results and traces will be stored in the results.
The display shows the same information as for the Pset execution, with the following differences:
Pset being executed. When the Pset batch is completed, the next Pset
is automatically loaded.
